ASP.NET Core Hosting - Using Swagger with ASP.NET Core

clock October 12, 2018 12:11 by author Kenny

Swagger is an auto-magically generated API documenting tool. It takes any standard Web API project and can generate amazing looking (And functioning) docs without a user having to write a single additional line of documentation. Best of all, it can be as simple as a 2 line setup, or as complex as adding additional info to every single API endpoint to explode the level of info inside Swagger.

Getting Started

For the purpose of this guide, I’m just going to be using the standard ASP.net Core Web API template when you create a new project from Visual Studio. But any existing API will work just fine too!

First off, install the following Nuget package from your package manager console.

Install-Package Swashbuckle.AspNetCore

Next in the ConfigureServices method of your startup.cs, add the following code to add the Swagger services to your application.

public void ConfigureServices(IServiceCollection services)
{
 services.AddMvc();

 services.AddSwaggerGen(swagger =>
 {
  swagger.SwaggerDoc("v1", new Swashbuckle.AspNetCore.Swagger.Info { Title = "My First Swagger" });
 });
}

A couple of things to note here, firstly that inside the SwaggerGen lambda you can actually specify a few more details. As an example :

services.AddSwaggerGen(swagger =>
{
 swagger.DescribeAllEnumsAsStrings();
 swagger.DescribeAllParametersInCamelCase();
 swagger.SwaggerDoc("v1", new Swashbuckle.AspNetCore.Swagger.Info { Title = "My First Swagger" });
});

Here we have said for any enum instead of using the integer value, use the string. And for all parameters can we please use CamelCase. The defaults usually suit most, but if there are specific things you are looking for your docs, you can probably find the setting here.

Secondly is obviously the Info object. Here you can specify things like the documentation author, title, and license among other things.

Head down to the Configure method of your Startup.cs.Add a call to “UseSwagger” and a call to “UseSwaggerUI” Both of these should come before the call to UseMVC.

public void Configure(IApplicationBuilder app, IHostingEnvironment env, ILoggerFactory loggerFactory)
{
 app.UseSwagger();
 app.UseSwaggerUI(c =>
 {
  c.SwaggerEndpoint("/swagger/v1/swagger.json", "My First Swagger");
 });

 app.UseMvc();
}

And that’s it! Navigate your browser to https://localhost:{yourport}/swagger  to view your new API documentation.

If you don’t see anything, or it looks a bit odd, jump to the end of this article for a quick trouble shooting session!

XML Comments

The documentation that is auto generated is usually pretty damn good and if you are building a restful API, is usually enough to explain the functions of your API on their own. But there are times when the API needs a bit more explaining. For that, you can use XML Comments on your API action. For example :

/// <summary>
/// Gets a value by ID.
/// </summary>
/// <param name="id">The id of the value you wish to get.</param>
/// <returns></returns>
[HttpGet("{id}")]
public string Get(int id)
{
 return "value";
}

If you are using Visual Studio, you can type three forward slashes in a row and it will auto generate a skeleton set of comments for you. Most importantly is the summary and parameter descriptions that are free text. They are invaluable for being able to explain what an endpoint does and what input it expects.

Next you need to force your application to actually generate the XML data that Swagger can then read. Right click on your project in Visual Studio and select Properties. On the panel that opens up, select “Build” on the left hand side. You should see an option for “Output”, and a checkbox for “Xml documentation file”. Tick this box and the setting will be auto filled out for you.

Note that this setting is per build configuration. If you intend to use Swagger remotely (And therefore likely be built in Release mode before deploying), then you should change the Configuration setting up top on this panel to “Release” and then retick the documentation tickbox.

If you are not using Visual Studio, or you are just interested in how things work behind the scenes. Doing all of this just adds the following line to your csproj file.

<PropertyGroup Condition="'$(Configuration)|$(Platform)'=='Debug|AnyCPU'">
<DocumentationFile>bin\Debug\netcoreapp2.0\SwaggerExample.xml</DocumentationFile>
</PropertyGroup>
Next you need to head back to the ConfigureServices method of your startup.cs and add a call to IncludeXmlComments in your Swagger configuration.
services.AddSwaggerGen(swagger =>
{
 swagger.SwaggerDoc("v1", new Swashbuckle.AspNetCore.Swagger.Info { Title = "My First Swagger", Version = "v1" });
 swagger.IncludeXmlComments(Path.Combine(PlatformServices.Default.Application.ApplicationBasePath, "SwaggerExample.xml"));
});

Where SwaggerExample.xml is the xml file you set in your csproj/project configuration.

When you view Swagger again you should now see your XML comments displayed inside the documentation.

Up the top right is our description of our endpoint. And in the id row for our parameters, we also have a description value.

Describing API Response Codes

There may be times where your API returns a non “200” response code that you want to provide documentation for. For example an error of 400 if a particular parameter doesn’t fit certain requirements.

The first step is to decorate your actions with a “Produces” attribute that describes all the possible return codes your endpoint will give out. At the same time you can describe that for a given code, what model you will be returning at the same time. So for example if when you return an error 400, you return a particular class that describes the error, you can define that here.

[HttpGet("{id}")]
[ProducesResponseType(typeof(string), 200)]
[ProducesResponseType(404)]
[ProducesResponseType(400)]
public string Get(int id)
{
 return "value";
}

A quick note that you don’t need to specify the return of 200, that is implied, but it’s nice to add anyway. When you view this endpoint in swagger, the non 200 return codes are displayed at the bottom of the endpoint description.

While this lets you know that certain responses are expected, it doesn’t actually give you the reason why they would be returned. For that, we turn again to XML comments.

/// <summary>
/// Gets a value by ID.
/// </summary>
/// <param name="id">The id of the value you wish to get.</param>
/// <returns></returns>
/// <response code="200">Value returned</response>
/// <response code="404">Value was not able to be found</response>
/// <response code="400">Id was below 0</response>
[HttpGet("{id}")]
[ProducesResponseType(typeof(string), 200)]
[ProducesResponseType(404)]
[ProducesResponseType(400)]
public string Get(int id)
{
 return "value";
}

Now when we view this endpoint in Swagger again we have the descriptions next to the response codes.

Troubleshooting

I can’t see anything

Check that the nuget package  Microsoft.AspNetCore.StaticFiles is installed in the project. This is required by Swagger to run. If you are unsure, just try installing the package again, this has seriously fixed the issue for me before.

I’m using MVC Core

If you are use the “MVCCore” service rather than just plain MVC. Then you need to explicitly add the API Explorer services. Confused? Head to your ConfigureServices method in your startup.cs. If you see this :

services.AddMvc();

Then you are fine. However if you see this :

services.AddMvcCore();

Then you need to manually add the ApiExplorer service.

services.AddMvcCore().AddApiExplorer();

I’m not using “Attribute Routing”

Then Swagger won’t work for you. You must be using attribute routing to use Swagger.

Best ASP.NET Core Hosting Recommendation

ASPHostPortal.com provides its customers with Plesk Panel, one of the most popular and stable control panels for Windows hosting, as free. You could also see the latest .NET framework, a crazy amount of functionality as well as Large disk space, bandwidth, MSSQL databases and more. All those give people the convenience to build up a powerful site in Windows server. ASPHostPortal.com offers ASP.NET hosting starts from $1/month only. They also guarantees 30 days money back and guarantee 99.9% uptime. If you need a reliable affordable ASP.NET Hosting, ASPHostPortal.com should be your best choice.



ASP.NET Core Hosting - Using Layered Architectures In ASP.NET

clock September 7, 2018 11:57 by author Kenny

One approach to designing Web applications is to focus on clearly defined layers of the application’s architecture. This approach is similar to the way an architect designs a building. If you’ve ever seen detailed construction plans for a skyscraper, you know the construction plans include separate blueprints for the foundation, frame, roof, plumbing, electrical, and other floors of the building.

With a layered architecture, specialists can design and develop the “floors” — called layers — independently, provided that the connections between the layers (the interfaces) are carefully thought out.

The layers should be independent of one another, as much as possible. Among other things, that means heeding a few must-dos and shalt-nots:

Each layer must have a clearly defined focus. To design the layers properly, you must clearly spell out the tasks and responsibilities of each layer.

Layers should mind their own business. If one layer is responsible for user interaction, only that layer is allowed to communicate with the user. Other layers that need to get information from the user must do so through the User Interface Layer.

Clearly defined protocols must be set up for the layers to interact with one another. Interaction between the layers occurs only through these protocols.

Note that the layers are not tied directly to any particular application. For example, an architecture might work equally well for an online ordering system and for an online forum. As a result, layered architecture has nothing to do with the ERDs that define a database or the Data Flow Diagrams that define how the data flows within the application. It’s a separate structure.

HOW MANY LAYERS?

There are several common approaches to application architecture that vary depending on the number of layers used. One common scheme is to break the application into two layers:

Application Layer: The design of the user interface and the implementation of business policies are handled in this layer. This layer may also handle transaction logic — the code that groups database updates into transactions and ensures that all updates within a transaction are made consistently.

Data Access Layer: The underlying database engine that supports the application. This layer is responsible for maintaining the integrity of the database. Some or all the transaction logic may be implemented in this layer.

In the two-layer model, the Application Layer is the ASP.NET Web pages that define the pages presented to the user as well as the code-behind files that implement the application’s logic. The Data Access Layer is the database server that manages the database, such as Microsoft SQL Server or Oracle.

Note that ASP.NET 2.0 doesn’t require that you place the application’s logic code in a separate code-behind file. Instead, you can intersperse the logic code with the presentation code in the same file. However, it’s almost always a good idea to use separate code-behind files to separate the application’s logic from its presentation code. All of the applications presented in this book use separate code-behind files.

The division between the Application and Data Access layers isn’t always as clear-cut as it could be. For performance reasons, transaction logic is often shifted to the database server (in the form of stored procedures), and business rules are often implemented on the database server with constraints and triggers. Thus, the database server often handles some of the application logic.

If this messiness bothers you, you can use a three-layer architecture, which adds an additional layer to handle business rules and policies:

Presentation Layer: This layer handles the user interface.

Business Rules Layer: This layer handles the application’s business rules and policies. For example, if a sales application grants discounts to certain users, the discount policy is implemented in this layer.

Data Access Layer: The underlying database model that supports the application.

Creating a separate layer for business rules enables you to separate the rules from the database design and the presentation logic. Business rules are subject to change. By placing them in a separate layer, you have an easier task of changing them later than if they’re incorporated into the user interface or database design.

MODEL-VIEW-CONTROLLER

Another common model for designing Web applications is called Model-View-Controller (MVC). In this architecture, the application is broken into three parts:

Model: The model is, in effect, the application’s business layer. It usually consists of objects that represent the business entities that make up the application, such as customers and products.

View: The view is the application’s user interface. In a Web application, this consists of one or more HTML pages that define the look and feel of the application.

Controller: The controller manages the events processed by the application. The events are usually generated by user-interface actions, such as the user clicking a button or selecting an item from a drop-down list.

In a typical ASP.NET application, the .aspx file implements the view; the model and controller functions are combined and handled by the code-behind file. Thus, the code-behind file can be thought of as the model-controller.

Best ASP.NET Hosting Recommendation

ASPHostPortal.com provides its customers with Plesk Panel, one of the most popular and stable control panels for Windows hosting, as free. You could also see the latest .NET framework, a crazy amount of functionality as well as Large disk space, bandwidth, MSSQL databases and more. All those give people the convenience to build up a powerful site in Windows server. ASPHostPortal.com offers ASP.NET hosting starts from $1/month only. They also guarantees 30 days money back and guarantee 99.9% uptime. If you need a reliable affordable ASP.NET Hosting, ASPHostPortal.com should be your best choice.



ASP.NET Core Hosting - Queues In .NET Core

clock August 24, 2018 11:39 by author Kenny

I was recently looking into the new Channel<T>  API in .NET Core (For an upcoming post), but while writing it up, I wanted to do a quick refresher of all the existing “queues” in .NET Core. These queues are also available in full framework (And possibly other platforms), but all examples are written in .NET Core so your mileage may vary if you are trying to run them on a different platform.

FIFO vs LIFO

Before we jump into the .NET specifics, we should talk about the concept of FIFO or LIFO, or “First In, First Out” and “Last In, Last Out”. For the concept of queues, we typically think of FIFO. So the first message put into the queue, is the first one that comes out. Essentially processing messages as they go into a queue. The concept of LIFO, is typically rare when it comes to queues, but in .NET there is a type called Stack<T>  that works with LIFO. That is, after filling the stack with messages/objects, the last one put in would then be the first one out. Essentially the order would be reversed.

Queue<T>

Queue<T>  is going to be our barebones simple queue in .NET Core. It takes messages, and then pops them out in order. Here’s a quick code example :

static void Main(string[] args)
{
    Queue<string> messageQueue = new Queue<string>();
    messageQueue.Enqueue("Hello");
    messageQueue.Enqueue("World!");

    Console.WriteLine(messageQueue.Dequeue());
    Console.WriteLine(messageQueue.Dequeue());
    Console.ReadLine();
}

Pretty stock standard and not a lot of hidden meaning here. The Enqueue  method puts a message on our queue, and the Dequeue  method takes one off (In a FIFO manner). Our console app obviously prints out two lines, “Hello” then “World!”.

Barring multi threaded scenarios (Which we will talk about shortly), you’re not going to find too many reasons to use this barebones queue. In a single threaded app, you might pass around a queue to process a “list” of messages, but you may find that using a List<T>  within a loop is a simpler way of achieving the same result. Infact if you look at the source code of Queue, you will see it’s actually just an implementation of IEnumerable anyway!

So how about multi threaded scenarios? It kind of makes sense that you may want to load up a queue with items, and then have multiple threads all trying to process the messages. Well using a queue in this manner is actually not threadsafe, but .NET has a different type to handle multi threading…

ConcurrentQueue<T>

ConcurrentQueue<T>  is pretty similar to Queue<T> , but is made threadsafe by a copious amount of spinlocks. A common misconception is that ConcurrentQueues are just a wrapper around a queue with the use of the lock  keyword. A quick look at the source code here shows that’s definitely not the case. Why do I feel the need to point this out? Because I often see people try and make their use of Queue<T>  threadsafe by using locks, thinking that they are doing what Microsoft does when using ConcurrentQueue, but that’s pretty far from the truth and actually takes a pretty big performance hit when doing so.

Here’s a code sample of a ConcurrentQueue :

static void Main(string[] args)
{
    ConcurrentQueue<string> concurrentQueue = new ConcurrentQueue<string>();
    concurrentQueue.Enqueue("Hello");
    concurrentQueue.Enqueue("World!");

    string message;
    while(concurrentQueue.TryDequeue(out message))
    {
        Console.WriteLine(message);
    }

    Console.ReadLine();
}

So you’ll notice we can no longer just dequeue a message, we need to TryDequeue. It will return true if we managed to pop a message, and false if there is no message to pop.

Again, the main point of using a ConcurrentQueue over a regular Queue is that it’s threadsafe to have multiple consumers (Or producers/enqueuers) all using it at the same time.

BlockingCollection<T>

A blocking collection is an interesting “wrapper” type that can go over the top of any IProducerConsumerCollection<T>  type (Of which Queue<T>  and ConcurrentQueue<T>  are both). This can be handy if you have your own implementation of a queue, but for most cases you can roll with the default constructor of BlockingCollection. When doing this, it uses a ConcurrentQueue<T> under the hood making everything threadsafe (See source code here). The main reason to use a BlockingCollection is that it has a limit to how many items can sit in the queue/collection. Obviously this is beneficial if your producer is much faster than your consumers.

Let’s take a quick look :

static void Main(string[] args)
{
    BlockingCollection<string> blockingCollection = new BlockingCollection<string>(2);
    Console.WriteLine("Adding Hello");
    blockingCollection.Add("Hello");
    Console.WriteLine("Adding World!");
    blockingCollection.Add("World!");
    Console.WriteLine("Adding Good");
    blockingCollection.Add("Good");
    Console.WriteLine("Adding Evening");
    blockingCollection.Add("Evening!");

    Console.ReadLine();
}

What will happen with this code? You will see “Adding Hello”, “Adding World!”, and then nothing… Your application will just hang. The reason is this line :

BlockingCollection<string> blockingCollection = new BlockingCollection<string>(2);

We’ve initialized the collection to be a max size of 2. If we try and add an item where the collection is already at this size, we will just wait until a message is dequeued. How long will we wait? Well by default, forever. However we can change our add line to be :
blockingCollection.TryAdd("Hello", TimeSpan.FromSeconds(60));

So we’ve changed our Add call to TryAdd, and we’ve specified a timespan to wait. If this timespan is hit, then the TryAdd method will return false to let us know we weren’t able to add the item to the collection. This is handy if you need to alert someone that your queue is overloaded (e.g. the consumers are stalled for whatever reason).

Stack<T>

As we talked about earlier, a Stack<T> type allows for a Last In, First Out (LIFO) queuing style. Consider the following code :

static void Main(string[] args)
{
    Stack<string> stack = new Stack<string>();
    stack.Push("Hello");
    stack.Push("World!");

    Console.WriteLine(stack.Pop());
    Console.WriteLine(stack.Pop());

    Console.ReadLine();
}

The output would be “World!” then “Hello”. It’s rare that you would need this reversal of messages, but it does happen. Stack<T>  also has it’s companion in ConcurrentStack<T> , and you can initialize BlockingCollection with a ConcurrentStack within it.

Best ASP.NET Hosting Recommendation

ASPHostPortal.com provides its customers with Plesk Panel, one of the most popular and stable control panels for Windows hosting, as free. You could also see the latest .NET framework, a crazy amount of functionality as well as Large disk space, bandwidth, MSSQL databases and more. All those give people the convenience to build up a powerful site in Windows server. ASPHostPortal.com offers ASP.NET hosting starts from $1/month only. They also guarantees 30 days money back and guarantee 99.9% uptime. If you need a reliable affordable ASP.NET Hosting, ASPHostPortal.com should be your best choice.



ASP.NET Core 2 Hosting - Create ASP.NET Chart Control from Database using C#

clock August 10, 2018 11:11 by author Kenny

In this article I will explain with an example, how you can display charts in ASP.Net using new Chart Control.

Web.Config Modifications

You will need to modify the Web.Config file as following shown in order to use the ASP.Net 4.0 Chart control.

<configuration>
    <appSettings>
        <add key="ChartImageHandler" value="storage=file;timeout=20;" />
    </appSettings>
    <connectionStrings>
        <add name="conString"
        connectionString="Data Source=.\SQL2005;database=Northwind;Integrated Security=true"/>
    </connectionStrings>

    <system.web>
        <compilation debug="true" targetFramework="4.0">
            <assemblies>
                <add assembly="System.Web.DataVisualization, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31BF3856AD364E35"/>
            </assemblies>
        </compilation>
        <httpHandlers>
            <add path="ChartImg.axd" verb="GET,HEAD,POST" type="System.Web.UI.DataVisualization.Charting.ChartHttpHandler, System.Web.DataVisualization, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35" validate="false"/>
        </httpHandlers>
        <pages>
            <controls>
                <add tagPrefix="asp" namespace="System.Web.UI.DataVisualization.Charting" assembly="System.Web.DataVisualization, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35"/>
            </controls>
        </pages>
    </system.web>
    <system.webServer>
        <handlers>
            <remove name="ChartImageHandler"/>
            <add name="ChartImageHandler" preCondition="integratedMode" verb="GET,HEAD,POST" path="ChartImg.axd" type="System.Web.UI.DataVisualization.Charting.ChartHttpHandler, System.Web.DataVisualization, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35"/>
        </handlers>
    </system.webServer>
</configuration>

HTML Markup

Below is the HTML Markup of the page. It has an ASP.Net DropDownList and an ASP.Net Chart Control. The DropDownList is populated with countries and when a country is selected, the chart is populated with the statistics of orders of different cities in the selected country.

<asp:DropDownList ID="ddlCountries" runat="server" OnSelectedIndexChanged="ddlCountries_SelectedIndexChanged"
    AutoPostBack = "true">
</asp:DropDownList><hr />
<asp:Chart ID="Chart1" runat="server" Height="300px" Width="400px" Visible = "false">
    <Titles>
        <asp:Title ShadowOffset="3" Name="Items" />
    </Titles>
    <Legends>
        <asp:Legend Alignment="Center" Docking="Bottom" IsTextAutoFit="False" Name="Default" LegendStyle="Row" />
    </Legends>
    <Series>
        <asp:Series Name="Default" />
    </Series>
    <ChartAreas>
        <asp:ChartArea Name="ChartArea1" BorderWidth="0" />
    </ChartAreas>
</asp:Chart>

Namespaces

You will need to import the following Namespaces.

C#

using System.Data;
using System.Data.SqlClient;
using System.Configuration;

Populating the DropDownList and Chart

Inside the Page Load event, the DropDownList is populated with Countries from the Orders table of the Northwind database. When a Country is selected in the DropDownList, the statistical records of Ship Cities and their Total Orders are fetched from the Orders table. The Ship City values are assigned to the X point values of the Chart while the Total Orders value for the Ship Cities are assigned to the Y point values of the Chart. Finally using these values the Chart is populated and displayed.

C#

protected void Page_Load(object sender, EventArgs e)
{
    if (!IsPostBack)
    {
        string query = "select distinct shipcountry from orders";
        DataTable dt = GetData(query);
        ddlCountries.DataSource = dt;
        ddlCountries.DataTextField = "shipcountry";
        ddlCountries.DataValueField = "shipcountry";
        ddlCountries.DataBind();
        ddlCountries.Items.Insert(0, new ListItem("Select", ""));
    }
}

protected void ddlCountries_SelectedIndexChanged(object sender, EventArgs e)
{
    Chart1.Visible = ddlCountries.SelectedValue != "";
    string query = string.Format("select shipcity, count(orderid) from orders where shipcountry = '{0}' group by shipcity", ddlCountries.SelectedValue);
    DataTable dt = GetData(query);
    string[] x = new string[dt.Rows.Count];
    int[] y = new int[dt.Rows.Count];
    for (int i = 0; i < dt.Rows.Count; i++)
    {
        x[i] = dt.Rows[i][0].ToString();
        y[i] = Convert.ToInt32(dt.Rows[i][1]);
    }
    Chart1.Series[0].Points.DataBindXY(x, y);
    Chart1.Series[0].ChartType = SeriesChartType.Pie;
    Chart1.ChartAreas["ChartArea1"].Area3DStyle.Enable3D = true;
    Chart1.Legends[0].Enabled = true;
}

private static DataTable GetData(string query)
{
    DataTable dt = new DataTable();
    SqlCommand cmd = new SqlCommand(query);
    String constr = ConfigurationManager.ConnectionStrings["ConString"].ConnectionString;
    SqlConnection con = new SqlConnection(constr);
    SqlDataAdapter sda = new SqlDataAdapter();
    cmd.CommandType = CommandType.Text;
    cmd.Connection = con;
    sda.SelectCommand = cmd;
    sda.Fill(dt);
    return dt;
}

Best ASP.NET Hosting Recommendation


ASPHostPortal.com provides its customers with Plesk Panel, one of the most popular and stable control panels for Windows hosting, as free. You could also see the latest .NET framework, a crazy amount of functionality as well as Large disk space, bandwidth, MSSQL databases and more. All those give people the convenience to build up a powerful site in Windows server. ASPHostPortal.com offers ASP.NET hosting starts from $1/month only. They also guarantees 30 days money back and guarantee 99.9% uptime. If you need a reliable affordable ASP.NET Hosting, ASPHostPortal.com should be your best choice.



ASP.NET Hosting - ASPHostPortal.com :: Tips to configure Kestrel URLs in ASP.NET Core RC2

clock June 10, 2016 19:44 by author Armend

How to configure Kestrel URLs in ASP.NET Core RC2

ASP.NET Core is completely decoupled from the web server environment that hosts the application. ASP.NET Core supports hosting in IIS and IIS Express, and self-hosting scenarios using the Kestrel and WebListener HTTP servers. Additionally, developers and third party software vendors can create custom servers to host their ASP.NET Core apps.

Prior to the release of ASP.NET Core RC2 Kestrel would be configured as part of the command bindings in project.json:

"commands": {
  "web": "Microsoft.AspNet.Server.Kestrel --server.urls=http://localhost:60000;http://localhost:60001;"
},

If no URLs were specified, a default binding of http://localhost:5000 would be used.

As of RC2 we have a new unified toolchain (the .NET Core CLI) and ASP.NET Core applications are effectively just .NET Core Console Applications. They have a single entry point where we programatically configure and run the web host:

public static void Main(string[] args)
{
    var host = new WebHostBuilder()
        .UseKestrel()
        .UseContentRoot(Directory.GetCurrentDirectory())
        .UseIISIntegration()
        .UseStartup<Startup>()
        .Build();
    host.Run();
}

Here we're adding support for both Kestrel and IIS hosts via the appropriate extension methods.
When we upgraded SaasKit to RC2 we used the UseUrls extension to configure the URLs Kestrel would bind to:

var host = new WebHostBuilder()
    .UseKestrel()
    .UseContentRoot(Directory.GetCurrentDirectory())
    .UseUrls("http://localhost:60000", "http://localhost:60001")
    .UseIISIntegration()
    .UseStartup<Startup>()
    .Build();

I didn't really like this approach as we're hard-coding URLs. Fortunately it's still possible to load the Kestrel configuration from an external file.
First create a hosting.json file in the root of your application with your required bindings. Separate multiple URLs with a semi-colon:

{
  "server.urls": "http://localhost:60000;http://localhost:60001"
}

Next update Program.cs to load your hosting configuration, then use the UseConfiguration extension to pass the configuration to the WebHostBuilder:

public static void Main(string[] args)
{
    var config = new ConfigurationBuilder()
        .SetBasePath(Directory.GetCurrentDirectory())
        .AddJsonFile("hosting.json", optional: true)
        .Build();
    var host = new WebHostBuilder()
        .UseKestrel()
        .UseConfiguration(config)
        .UseContentRoot(Directory.GetCurrentDirectory())
        .UseIISIntegration()
        .UseStartup<Startup>()
        .Build();
    host.Run();
}

If you're launching Kestrel with Visual Studio you may also need to update launchSettings.json with the correct launchUrl:

"RC2HostingDemo": {
  "commandName": "Project",
  "launchBrowser": true,
  "launchUrl": "http://localhost:60000/api/values",
  "environmentVariables": {
    "ASPNETCORE_ENVIRONMENT": "Development"
  }
}

Now the web application will listen on the URLs configured in hosting.json:

Hosting environment: Development
Content root path: C:\Users\ben\Source\RC2HostingDemo\src\RC2HostingDemo
Now listening on: http://localhost:60000
Now listening on: http://localhost:60001
Application started. Press Ctrl+C to shut down.



ASP.NET Hosting - ASPHostPortal.com :: How to Check Duplicate User Names In ASP.NET Web Pages Sites

clock October 5, 2015 11:39 by author Kenny

How to Check Duplicate User Names In ASP.NET Web Pages Sites

The Web Pages Starter Site template provides a useful starting point for developing a Razor Web Pages site that includes membership. But it doesn't include any mechanism for preventing duplicate user names. This article offers one solution to the problem that uses jQuery.

If you ask how to prevent duplicate user names in forums, one of the suggestions that is often put forward is to apply a unique constraint in the database column that holds the user name. Any attempt to submit a duplicate value will result in an exception being raised in the relevant database provider. You can catch this exception and show the user an appropriate message. This works but it's a fairly clunky solution. And many people feel that you should not use exceptions as a means to manage your business rules.

The solution featured in this article uses AJAX to query the database and to give the user immediate feedback when they enter their chosen user name. The AJAX call requests a page that exists purely to query the database to see if the selected user name is already in use. The solution also includes a server side chekc to ensure that users who have disabled JavaScript so not slip through the net. The solution requires a couple of amendments to the Register.cshtml file in the Starter Site, and the addition of 3 files. But first, the changes to the Register.cshtml page. The first change is in the inclusion of a JavaScript file called dupecheck.js.

@* Remove this section if you are using bundling *@
@section Scripts {
    <script src="~/Scripts/jquery.validate.min.js"></script>
    <script src="~/Scripts/jquery.validate.unobtrusive.min.js"></script>
    <script src="~/Scripts/dupecheck.js"></script>
}

And the second is the server side check to see if the username is in use:

if(Functions.IsDuplicate(email)){
    ModelState.AddError("email", "User name is already taken");
}

I placed this in the if(IsPost) section just after the initial variables that represent the submitted values (email, password and confirmPassword) are declared. The code calls a function named IsDuplicate. The function is declared in a file called Functions.cshtml which is placed in a folder called App_Code:

@functions {
    public static bool IsDuplicate(string username){
        var db = Database.Open("StarterSite");
        var commandText = @"SELECT COUNT(Email) FROM UserProfile WHERE Email = @0";
        return (int)db.QueryValue(commandText, username) > 0;
    }
}

Note that the name of the folder is important. The function returns a bool. The value of the bool is determined as a result if the SQL query which gets a count of the rows containing the provided user name. By default, the Starter Site uses a column called Email in the UserProfile table for the storage of user names. This function is also called in a separate file named DupeCheck.cshtml. This file is placed in the root of the site:

@{
    Layout = null;
    if(IsAjax){
        var username = Request["username"];
        var result = Functions.IsDuplicate(username);
        Json.Write(new { isDupe = result }, Response.Output);
    }
}

DupeCheck.cshtml is designed to work exclusively with AJAX. The code includes an instruction to nullify any layout pages that might have been set in a _PageStart file, and then it uses the IsAjax property to determine if the page has been requested via an AJAX call. If it has, it uses the IsDuplicate method to check the availability of the posted username and returns the result to the calling code. The result is an anonymous type that has one propery: isDupe, which is a boolean. The anonymous type is serialised to JSON by the Json helper.

The final part of the solution is the dupecheck.js file. This uses jQuery:

$(function () {
    $('#email').change(function () {
        $.post(
            '/DupeCheck',
            { username: $(this).val() },
            function (data) {
                var emailValidation = $('span[data-valmsg-for="email"]');
                if (data.isDupe) {
                    if (emailValidation.hasClass('field-validation-valid')) {
                        emailValidation.removeClass('field-validation-valid');
                        emailValidation.addClass('field-validation-error');
                        emailValidation.text('That name is already taken!');
                    }
                } else {
                    if (emailValidation.hasClass('field-validation-error')) {
                        emailValidation.removeClass('field-validation-error');
                        emailValidation.addClass('field-validation-valid');
                        emailValidation.text('');
                    }
                }
            },'json'
        );
    });
});

An event handler is attached to the change event of the user name input (which has an id if email in the Starter Site). The current value is posted to the DupeCheck.cshtml page via AJAX. The code above checks the response from the server to see if the value is a duplicate, and if it is, an appropriate error message is displayed to the user.

Best ASP.NET 4.6 Hosting Recommendation

ASPHostPortal.com provides its customers with Plesk Panel, one of the most popular and stable control panels for Windows hosting, as free. You could also see the latest .NET framework, a crazy amount of functionality as well as Large disk space, bandwidth, MSSQL databases and more. All those give people the convenience to build up a powerful site in Windows server. ASPHostPortal.com offers ASP.NET hosting starts from $1/month only. They also guarantees 30 days money back and guarantee 99.9% uptime. If you need a reliable affordable ASP.NET Hosting, ASPHostPortal.com should be your best choice.



ASP.NET Hosting - ASPHostPortal.com :: Easy to Design Pie Chart and Donut Chart in ASP.NET

clock September 28, 2015 12:40 by author Kenny

Easy to Design Pie Chart and Donut Chart in ASP.NET

D3.js stands for Data-Driven Document. It is a JavaScript library using which we can manipulate documents based on data. The data can be fetched using multiple ways like Web Services, WCF Services, REST APIs or the relatively new Microsoft ASP.NET Web API amongst many others. Using D3, you can bind the data to the Document Object Model (DOM) and present that data with rich visualizations. D3 internally makes use of CSS, HTML and SVG capabilities to make your data presentable. It is powerful, fast and supports large datasets and dynamic behaviors for interactions and powerful and smooth animations.

D3.js provides easy and declarative selections of DOM nodes using W3C Selector APIs. D3 Selector APIs provides number of methods to manipulate nodes. For example –

  • Setting attributes and applying rich styles
  • Registering Event Listeners
  • You can add, remove and sort DOM nodes
  • You can change the HTML or the text contents of HTML elements
  • You can also have a direct selection/access to the DOM as each selection is an array of nodes

Likewise, we have various features of D3.js selectors which we can use to present data to our DOM nodes.

A simple selector example is the following:

var bodySelection = d3.select('body').style('background-color', 'blue');

In the above example, we are selecting body and changing its background color to blue. Another example would be as follows:

var divSelection = d3.selectAll('div').style('background-color', 'yellow');

In the above example, we are selecting all divs and changing its background color to yellow. If you are familiar with jQuery, the syntax looks similar to jQuery selectors or HTML5 Selectors.

D3 allows us to bind the data to the DOM elements and their attributes using a Data method which takes an array. For example:

d3.selectAll("div")
  .data([200,300,400,100])
  .style("height", function (data) { return data + "px"; });

In the above example, we are selecting all the div’s on the page and based on the index, the first value of an array will be passed to first div, second value to second div and so on.

In D3, you can also make use of Enter and Exit selector methods to create new nodes for incoming data, and remove outing nodes that are no longer used.

You can also apply transitions to nodes using D3. For example –

var area = d3.select('body')
            .append('svg')
            .attr('width', 500)
            .attr('height', 500);

var circle = area.append('rect')
                 .attr('width', 100)
                 .attr('height', 100)
                 .attr('fill', 'red');

circle.transition()
      .duration(2000)
      .delay(2000)
      .attr('width', 400)
      .each('start', function () {
            d3.select(this).attr('fill', 'green');})
      .transition()
      .duration(2000)
      .attr('height', 400)
      .transition()
      .duration(2000)
      .attr('width', 50)
      .transition()
      .duration(2000)
      .attr('height', 50)
      .each('end', function () {
            d3.select(this).attr('fill', 'blue'); });

In the above example, we are drawing a Rectangle and applying the transition to the same. Likewise, we can make use of various features of D3.js to present our data using rich visualizations.

A Quick overview of ASP.NET Web API

REST(REpresentational State Transfer) has emerged as the prominent way to create web services. By using REST we can build loose coupled services with data available on the web over HTTP protocol.

ASP.NET Web API is a platform for building RESTful applications. ASP.NET Web API is a framework using which we can build HTTP Services which can be called from a broad range of clients, browsers and mobile devices. ASP.NET Web API is the defacto standard of creating web services and replaces WCF.

When we think about exposing data on the web, we usually talk about four common operations which we use on a daily basis in our apps – CREATE, RETRIVE, UPDATE, DELETE.

We call these operations as CRUD operations. REST provides 4 basic HTTP verbs which we can map to our CRUD operations as described here - POST – CREATE, GET – RETRIVE, PUT – UPDATE, DELETE – DELETE.

By using REST, if you can connect to the web, any application can consume your data. When the data is pulled or pushed by using REST, the data is always serialized into or de-serialized from JSON or XML.

Setting up the application and ASP.NET Web API

To start designing the Pie chart and Donut chart, use the following tools and technologies:

  • Microsoft Visual Studio 2013 (Express or Professional)
  • Microsoft SQL Server 2012 (Express or Developer)
  • jQuery
  • D3.js
  • ASP.NET WEB API

Let’s first design the table where we can add our data. To design the table, open SQL Server Management Studio and write the following script:

CREATE TABLE [dbo].[CityPopulationTable](
    [CityID] [int] IDENTITY PRIMARY KEY,
    [CityName] [nvarchar](30) NULL,
    [Population] [int] NULL
)

Create an ASP.NET Web application by choosing Web Forms template. Then add the Entity Framework, jQuery and D3.js libraries into our web application using NuGet.

Once you add these libraries, right click on the Models folder in our Web application under Solution Explorer, and click on Add New Item. Choose Data  > ADO.NET Entity Data Model.

Using Entity Data Model Wizard, connect to our database and choose CityPopulationTable.

It’s time to implement the ASP.NET Web API into our project. Right click the web application and add a new folder with the name Controllers.

After adding the Web API, open Global.asax file and import two namespaces as shown here:

using System.Web.Http;
using System.Web.Routing;

Also add the following code to the Application_Start method –

GlobalConfiguration.Configure(WebApiConfig.Register);

The above line registers the Web API route in our web application. Now under App_Start folder, you will find WebApiConfig.cs file. Open this file and write the following code:

public static void Register(HttpConfiguration config)
{
    config.MapHttpAttributeRoutes();

    config.Routes.MapHttpRoute(
        name: "DefaultApi",
        routeTemplate: "api/{controller}/{id}",
        defaults: new { id = RouteParameter.Optional }
    );
    var json = config.Formatters.JsonFormatter;
    json.SerializerSettings.PreserveReferencesHandling = Newtonsoft.Json.PreserveReferencesHandling.Objects;
    json.SerializerSettings.ContractResolver = new CamelCasePropertyNamesContractResolver();
    config.Formatters.Remove(config.Formatters.XmlFormatter);
}

In the above code, we are configuring Web API to make use of JSON formatter with camel casing, as most of the JavaScript developer will expect JSON output in Camel casing.

Now modify the Get method of our Web API controller as shown here:

public class PieChartController : ApiController
{
    NorthwindEntities dataContext = new NorthwindEntities();
    // GET api/piechart
    public IEnumerable<CityPopulationTable> Get()
    {
        return dataContext.CityPopulationTables.ToList();
    }
}

In the above code, we have created an object of our Entity Data model which will give access to the tables. Then we are returning an IEnumerable of our object CityPopulationTables.

Let us design our Pie chart and Donut chart using the Web API data shown in above:

Creating D3 Charts

Add a HTML page with the name ‘CityPolulationPieChart.html’. Once you add the page, we will reference the jQuery and D3.js file in the page:

<!DOCTYPE html>
<html lang="en">
<head>
    <title>Pie Chart Example</title>
    <script src="Scripts/jquery-1.10.2.js"></script>
    <script src="Scripts/d3.js"></script>
</head>

We will make use of jQuery AJAX function to fetch the data from our Web API and display it in a Pie and Donut chart. Let’s add a DOM ready function into our <body> tag. In this function, we will first declare two arrays. First array will hold the data for our chart and the second array will hold the colors which we will use for our chart:

$(function () {
            var chartData = [];
            var colors = [];
});

In the next step, we will fetch the data from our Web API using jQuery $.ajax function. Add this code after our array declaration:

$.ajax({
        type: "GET",
        url: "api/PieChart",
        contentType: "application/json; charset=utf-8",
        dataType: "json",
        success: function (result) {
            $.each(result, function (i,j) {
                chartData.push(j.population);
                var currentColor = '#' + Math.floor(Math.random() * j.population+5566656).toString(16);
                colors.push(currentColor);
            });
            console.log(chartData);}
        error: function (msg) {
            $("#result").text(msg);
        }
});

Note: Although I have used success and error here for devs using an older version of jQuery, these methods have been deprecated from jQuery 1.8. You should replace them with .done() and fail().

In the above code, we are using a GET request with the Web API URL and the type of data set to JSON. On successful completion of the request, we are running a loop using $.each() which will push the fetched data into our chartData array. We are also generating colors and adding them into our colors array.

Now it’s time to use the D3 selector. We will use D3 selector to select the body and will append the SVG element to the same by setting its height and width. Add this code after console.log function. The code is shown below –

var radius = 300;
var colorScale = d3.scale.ordinal().range(colors);

var area = d3.select('body').append('svg')
             .attr('width', 1500)
             .attr('height', 1500);

Also note that we are using the scale function of D3 which allows us to set the ordinal scale with the range to set the scale’s output range. We have also added a variable called radius which is set to 300.

The next step is to group the elements and draw an arc into our SVG as shown in the following code:

var pieGroup = area.append('g').attr('transform', 'translate(300, 300)');
var arc = d3.svg.arc()
                .innerRadius(0)
                .outerRadius(radius);

In the above code, we are using radius variable as the outer radius and fixing the inner radius to 0. As the next step, use a pie layout available under D3. Then pass the chart data and append it to our group ‘g’. The code is shown below –

var pie = d3.layout.pie()
       .value(function (data) { return data; })
var arcs = pieGroup.selectAll('.arc')
       .data(pie(chartData))
       .enter()
       .append('g')
       .attr('class', 'arc');

Also observe, we are using D3 selector to select arc class added at the end, which will select all the elements which has a class arc. In the last step,  append the path and fill the color from our array. We will also display the population data as text to our pie chart. The code is shown below –

arcs.append('path')
    .attr('d', arc)
    .attr('fill', function (d) { return colorScale(d.data); });

arcs.append('text')
    .attr('transform', function (data) { return 'translate(' + arc.centroid(data) + ')'; })
    .attr('text-anchor', 'middle')
    .attr('font-size', '1em')
    .text(function (data) { return data.data; });

Donut Chart

Designing a Donut chart is very simple. Just change the inner radius to something higher than zero. I am making it 200. The code is as shown here:

var arc = d3.svg.arc()
        .innerRadius(200)
        .outerRadius(radius);

Best ASP.NET 4.6 Hosting Recommendation

ASPHostPortal.com provides its customers with Plesk Panel, one of the most popular and stable control panels for Windows hosting, as free. You could also see the latest .NET framework, a crazy amount of functionality as well as Large disk space, bandwidth, MSSQL databases and more. All those give people the convenience to build up a powerful site in Windows server. ASPHostPortal.com offers ASP.NET hosting starts from $1/month only. They also guarantees 30 days money back and guarantee 99.9% uptime. If you need a reliable affordable ASP.NET Hosting, ASPHostPortal.com should be your best choice.



ASP.NET MVC 6 Hosting - ASPHostPortal :: Remote Validation in ASP.NET MVC

clock August 24, 2015 08:07 by author Kenny

Remote Validation in ASP.NET MVC

ASP.NET is an open-source server-side Web application framework designed for Web development to produce dynamic Web pages. It was developed by Microsoft to allow programmers to build dynamic web sites, web applications and web services. ASP.NET MVC gives you a powerful, patterns-based way to build dynamic websites that enables a clean separation of concerns and that gives you full control over markup. Remote validation is used to make server calls to validate data without posting the entire form to the server when server side validation is preferable to client side.  It's all done set up model and controller which is pretty neat.

Using the Code

To implement remote validation in an application we have two scenarios, one is without an additional parameter and the other is with an additional parameter. First we create an example without an additional parameter. In this example we check whether a username exists or not. If the username exists then that means the input user name is not valid. We create a view model class "UserViewModel" under the Models folder and that code is:

using System.Web.Mvc;
namespace RemoteValidation.Models
{
    public class UserViewModel
    {
        public string UserName
        {
            get;
            set;
        }
        public string Email
        {
            get;
            set;
        }
    }
}



Now we create a static data source, in other words we create a static list of UserViewModel in which we could check whether a username exists or not. You can also use the database rather than a static list. The following code snippet is for StaticData.

using RemoteValidation.Models;
using System.Collections.Generic;

namespace RemoteValidation.Code
{
    public static class StaticData
    {
        public static List < UserViewModel > UserList
        {
            get {
                return new List < UserViewModel >
                {
                    new UserViewModel
                    {
                        UserName = "User1", Email = "[email protected]"
                    },
                    new UserViewModel
                    {
                        UserName = "User2", Email = "[email protected]"
                    }
                }
            }
        }
    }



Now we create a controller "ValidationController" in which we create an action method to check whether a user name exists or not and return a result as a JSON format. If the username exists then it returns false so that the validation is implemented on the input field. The following code snippet shows ValidationController under the Controllers folder.

using RemoteValidation.Code;
using System.Linq;
using System.Web.Mvc;

namespace RemoteValidation.Controllers
{
    public class ValidationController: Controller
    {
        [HttpGet]
        public JsonResult IsUserNameExist(string userName)
        {
            bool isExist = StaticData.UserList.Where(u = > u.UserName.ToLowerInvariant().Equals(userName.ToLower())).FirstOrDefault() != null;
            return Json(!isExist, JsonRequestBehavior.AllowGet);
        }
    }
}



Now we add remote validation on the UserName of the UserViewModel property as in the following code snippet.

using System.Web.Mvc;

namespace RemoteValidation.Models
{
    public class UserViewModel
    {
        [Remote("IsUserNameExist", "Validation", ErrorMessage = "User name already exist")]
        public string UserName
        {
            get;
            set;
        }
        public string Email
        {
            get;
            set;
        }
    }



As in the preceding code snippet, the IsUserNameExist is a method of ValidationController that is called on the blur of an input field using a GET request. Now we create UserController under the Controllers folder to render a view on the UI.

using RemoteValidation.Models;
using System.Web.Mvc;

namespace RemoteValidation.Controllers
{
    public class UserController: Controller
    {
        [HttpGet]
        public ActionResult AddUser()
        {
            UserViewModel model = new UserViewModel();
            return View(model);
        }
    }

Now we add jquery.validate.js and jquery.validate.unobtrusive.js to the project and create a bundle as in the following code snippet.

using System.Web.Optimization;

namespace RemoteValidation.App_Start
{
    public class BundleConfig
    {
        public static void RegisterBundles(BundleCollection bundles)
        {
            bundles.Add(new StyleBundle("~/Content/css").Include(
                "~/Content/css/bootstrap.css",
                "~/Content/css/font-awesome.css",
                "~/Content/css/site.css"));

            bundles.Add(new ScriptBundle("~/bundles/jquery").Include(
                "~/Scripts/jquery-{version}.js"));

            bundles.Add(new ScriptBundle("~/bundles/jqueryval").Include(
                "~/Scripts/jquery.validate*"));
        }
    }

Thereafter we add the following keys in the web.config file.

<add key="ClientValidationEnabled" value="true" />
<add key="UnobtrusiveJavaScriptEnabled" value="true" />



Thereafter we create a view for the AddUser action method. The following code snippet is for the AddUser view.

@model RemoteValidation.Models.UserViewModel

< div class = "panel panel-primary" > < div class = "panel-heading panel-head" > Add User < /div>
    <div class="panel-body">
        @using (Html.BeginForm())
        {
            <div class="form-horizontal">
                <div class="form-group">
                    @Html.LabelFor(model => model.UserName, new { @class = "col-lg-2 control-label" })
                    <div class="col-lg-9">
                        @Html.TextBoxFor(model => model.UserName, new { @class = "form-control" })
                        @Html.ValidationMessageFor(model => model.UserName)
                    </div > < /div>
                <div class="form-group">
                    @Html.LabelFor(model => model.Email, new { @class = "col-lg-2 control-label" })
                    <div class="col-lg-9">
                        @Html.TextBoxFor(model => model.Email, new { @class = "form-control" })
                        @Html.ValidationMessageFor(model => model.Email)
                    </div > < /div>
                <div class="form-group">
                    <div class="col-lg-9"></div > < div class = "col-lg-3" > < button class = "btn btn-success"
                     id = "btnSubmit"
                     type = "submit" > Submit < /button>
                    </div >
               < /div>
            </div >
} < /div>
</div >
@section scripts
{
    @Scripts.Render("~/bundles/jqueryval")

Let's run the application and put values into the user name field to execute the remote validation as in the following image.

Figure 1: Remote validation on user name


Now we move to another option, we pass an additional parameter in the remote validation. We pass both the user name and email as a parameter and check whether the username and email combination exist or not on the email input. That's why we add one more method in ValidationController as in the following code snippet for it.

[HttpGet]
public JsonResult IsUserExist(string email, string userName)
{
    bool isExist = StaticData.UserList.Where(u = > u.UserName.ToLowerInvariant().Equals(userName.ToLower()) && u.Email.ToLowerInvariant().Equals(email.ToLower())).FirstOrDefault() != null;
    return Json(!isExist, JsonRequestBehavior.AllowGet);

Now we call this method on the Email property of UserViewModel as in the following code snippet.

using System.Web.Mvc;

namespace RemoteValidation.Models
{
    public class UserViewModel
    {
        [Remote("IsUserNameExist", "Validation", ErrorMessage = "User name already exist")]
        public string UserName
        {
            get;
            set;
        }
        [Remote("IsUserExist", "Validation", ErrorMessage = "User already exist", AdditionalFields = "UserName")]
        public string Email
        {
            get;
            set;
        }
    }
}

As in the preceding code snippet, we are passing an additional field using AdditionalFields in Remote. If we must pass more than one parameter then these will be comma-separated. Now run the application and the result will be as shown in the following image.



ASP.NET 4.5 HOSTING - ASPHostPortal :: How to Create Nested WebGrid in ASP.NET MVC6.

clock November 19, 2014 05:51 by author Mark

How to Create Nested WebGrid with Expand/Collapse in ASP.NET MVC6.

Introduction

In this post, I am explain How to Create Nested WebGrid with Expand/Collapse in ASP.NET MVC6.
Steps :

Step - 1 : Create New Project.

  • Go to File > New > Project > Select asp.net MVC6 web application > Entry Application Name > Click OK > Select Internet Application > Select view engine Razor > OK

Step-2: Add a Database.

  • Go to Solution Explorer > Right Click on App_Data folder > Add > New item > Select SQL Server Database Under Data > Enter Database name > Add.

Step-3: Create table for fetch data.

  • Open Database > Right Click on Table > Add New Table > Add Columns > Save > Enter table name > OK.

In this example, I have used two tables as below

Step-4: Add Entity Data Model.

  • Go to Solution Explorer > Right Click on Project name form Solution Explorer > Add > New item > Select ADO.net Entity Data Model under data > Enter model name > Add.
  • A popup window will come (Entity Data Model Wizard) > Select Generate from database > Next >
  • Chose your data connection > select your database > next > Select tables > enter Model Namespace > Finish.

Step-5: Add a class for create a view model.

  • 1st : Add a folder.
  • Go to Solution Explorer > Right Click on the project > add > new folder.
  • 2nd : Add a class on that folder
  • Go to Solution Explorer > Right Click on that folder > Add > Class... > Enter Class name > Add.

Write the following code in this class

using System.Collections.Generic;
namespace MVCNestedWebgrid.ViewModel
{
    public class OrderVM
    {
        public OrderMaster order { get; set; }
        public List<OrderDetail> orderDetails { get; set; }
    }
}

Step-6: Add a new Controller.

  • Go to Solution Explorer > Right Click on Controllers folder form Solution Explorer > Add > Controller > Enter Controller name > Select Templete "empty MVC Controller"> Add.

Step-7: Add new action into your controller for show nested data in a webgrid.

Here I have added "List" Action into "Order" Controller. Please write this following code

public ActionResult List()
{
    List<OrderVM> allOrder = new List<OrderVM>();

    // here MyDatabaseEntities is our data context
    using (MyDatabaseEntities dc = new MyDatabaseEntities())
    {
        var o = dc.OrderMasters.OrderByDescending(a => a.OrderID);
        foreach (var i in o)
        {
            var od = dc.OrderDetails.Where(a => a.OrderID.Equals(i.OrderID)).ToList();
            allOrder.Add(new OrderVM { order= i, orderDetails = od });
        }
    }
    return View(allOrder);
}

Step-8: Add view for the Action & design.

  • Right Click on Action Method (here right click on form action) > Add View... > Enter View Name > Select View Engine (Razor) > Check "Create a strong-typed view" > Select your model class > Add.

NOTE " Please Rebuild solution before add view

Html Code
@model IEnumerable<MVCNestedWebgrid.ViewModel.OrderVM>

@{
    ViewBag.Title = "Order List";
    WebGrid grid = new WebGrid(source: Model, canSort: false);
}
<div id="main" style="padding:25px; background-color:white;">
    @grid.GetHtml(
    htmlAttributes: new {id="gridT", width="700px" },
    columns:grid.Columns(
            grid.Column("order.OrderID","Order ID"),
            grid.Column(header:"Order Date",format:(item)=> string.Format("{0:dd-MM-yyyy}",item.order.OrderDate)),
            grid.Column("order.CustomerName","Customer Name"),
            grid.Column("order.CustomerAddress","Address"),
            grid.Column(format:(item)=>{
                WebGrid subGrid = new WebGrid(source: item.orderDetails);
                return subGrid.GetHtml(
                    htmlAttributes: new { id="subT" },
                    columns:subGrid.Columns(
                            subGrid.Column("Product","Product"),
                            subGrid.Column("Quantity", "Quantity"),
                            subGrid.Column("Rate", "Rate"),
                            subGrid.Column("Amount", "Amount")
                        )
                    );
            })
        )
    )
</div>
Css Code
<style>
th, td {
        padding:5px;
    }
    th
    {
        background-color:rgb(248, 248, 248);
    }
    #gridT,  #gridT tr {
        border:1px solid #0D857B;
    }
    #subT,#subT tr {
        border:1px solid #f3f3f3;
    }
    #subT {
        margin:0px 0px 0px 10px;
        padding:5px;
        width:95%;
    }
    #subT th {
        font-size:12px;
    }
    .hoverEff {
        cursor:pointer;
    }
    .hoverEff:hover {
        background-color:rgb(248, 242, 242);
    }
    .expand {
        background-image: url(/Images/pm.png);
        background-position-x: -22px;
        background-repeat:no-repeat;
    }
    .collapse  {
        background-image: url(/Images/pm.png);
        background-position-x: -2px;
        background-repeat:no-repeat;
    }
</style>
Write the following Jquery code for make webgrid collapsible
<script>
    $(document).ready(function () {
        var size = $("#main #gridT > thead > tr >th").size(); // get total column
        $("#main #gridT > thead > tr >th").last().remove(); // remove last column
        $("#main #gridT > thead > tr").prepend("<th></th>"); // add one column at first for collapsible column
        $("#main #gridT > tbody > tr").each(function (i, el) {
            $(this).prepend(
                    $("<td></td>")
                    .addClass("expand")
                    .addClass("hoverEff")
                    .attr('title',"click for show/hide")
                );
            //Now get sub table from last column and add this to the next new added row
            var table = $("table", this).parent().html();
            //add new row with this subtable
            $(this).after("<tr><td></td><td style='padding:5px; margin:0px;' colspan='" + (size - 1) + "'>" + table + "</td></tr>");
            $("table", this).parent().remove();
            // ADD CLICK EVENT FOR MAKE COLLAPSIBLE
            $(".hoverEff", this).live("click", function () {
                $(this).parent().closest("tr").next().slideToggle(100);
                $(this).toggleClass("expand collapse");
            });
        });
        //by default make all subgrid in collapse mode
        $("#main #gridT > tbody > tr td.expand").each(function (i, el) {
            $(this).toggleClass("expand collapse");
            $(this).parent().closest("tr").next().slideToggle(100);
        });
    });
</script>



ASP.NET MVC SignalR Hosting - ASPHostPortal.com :: Create a Real-Time Message Board Making use of ASP.Net MVC 5, SignalR 2, and KnockoutJS

clock October 28, 2014 06:05 by author Ben

Have you ever questioned how Facebook sends you notifications the instant you receive a new information, friend request, or remark? Does the customer constantly look for new events? Doesn’t that consume a whole lot of memory within the user’s side? What sort of pressure does that place on Facebook’s servers?




Due to HTMl five as well as the support of web sockets in modern browsers, this performance can be achieved with out over-taxing the user or even the server. Leveraging a library like SignalR for .NET or Socket.IO for Node.js, most of the very hard perform around working with web sockets is already completed to suit your needs.

On this tutorial, we’re planning to build a real-time concept board, very similar to Facebook. Although this will not be something you should model and drive to manufacturing as-is, it could supply you with the fundamental groundwork for creating your own personal real-time net application.

Let's Start

Start the Project - Initial, begin a new ASP.Net MVC 5 project from Visual Studio 2013. You can title it what ever you want, but I named the undertaking “MessageBoardTutorial”. Make sure you place a checkmark close to "Web API".


Get dependencies with NuGet - Let’s go on and get downloading our required libraries out of the best way. We can get every thing with NuGet, saving us plenty of your time. Within the Remedy Explorer, right-click around the project name and click on “Manage NuGet Packages…” from the context menu.

Initial, you'll want to update all the packages presently set up to their newest variations. Be aware that because MVC 4, all the MVC libraries are bin deployed, so you will need to update them when commencing a fresh undertaking. On the still left, simply click on “Updates->nuget.org” and also you will see each of the offers that must be up-to-date. Just click on on “Update All” and allow NuGet do its thing.


When that's done, near the window. Open up the Package Supervisor Console in Tools > NuGet Package Manager > Package Manager Console. We must set up a few a lot more deals for this tutorial. Run the subsequent commands to set up the deals we need for this tutorial.

PM> Install-Package EntityFramework
PM> Install-Package Microsoft.AspNet.SignalR
PM> Install-Package Moment.js
PM> Install-Package KnockoutJS

NuGet will put in several dependencies that SignalR 2 needs. Additionally, you will get yourself a good tiny readme.txt. Feel free to read this, but we are going to be covering this listed here also.

The Front End

We are going to now truly commence coding. The Layout - First, we've got to go into the structure file and simplify issues somewhat - we don't truly require the responsive menu for this tutorial. Open /Views/Shared/_Layout.cshtml. It ought to now search such as this, assuming you failed to modify the default directories:

<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>@ViewBag.Title</title>
    @Styles.Render("~/Content/css")
    @Scripts.Render("~/bundles/modernizr")
</head>
<body>
    <div class="container body-content">
        @RenderBody()
    </div>

    @Scripts.Render("~/bundles/jquery")
    @Scripts.Render("~/bundles/bootstrap")
    @RenderSection("scripts", required: false)
</body>
</html>

Edit the Home Controller and Index View - We will only need a single controller and view for this software. Inside the Remedy Explorer, open Controllers > HomeController and take away all Steps except for Index.

Now, open up the Index check out and just delete every thing. If you are a neat freak like me, truly feel totally free to eliminate another views inside the Views > Home.

Edit the View - Under is the see for your application. In case you are new to KnockoutJS, a few of this may appear unfamiliar. I will clarify a lot more when we get to the JavaScript inside the up coming section. Just be aware that wherever the thing is a "data-bind" attribute, the component is joined into a JS worth we are tracking with Knockout.

We're mostly using regular CSS courses from Bootstrap. Bootstrap gives us a quick way to incorporate a responsive grid framework for our view. The still left column includes our "login" type and also the proper the information board itself.

@{
    ViewBag.Title = "Land of Ooobook";
}

<div class="jumbotron">
    <h1>Land of Ooobook</h1>
    <p>Candy Kingdom's Social Network</p>
</div>

<div class="container">
    <div class="row">
        <div class="col-md-4">
            <form class="pad-bottom" data-bind="visible: !signedIn(), submit: signIn">
                <div class="form-group">
                    <label for="username">Sign In</label>
                    <input class="form-control" type="text" name="username" id="username" placeholder="Enter your userame" />
                </div>
                <button type="submit" class="btn btn-primary">Sign In</button>
                <br />
            </form>

            <div data-bind="visible: signedIn">
                <p>You are signed in as <strong data-bind="text: username"></strong></p>
            </div>
        </div>
        <div class="col-md-8">
            <div data-bind="visible: notifications().length > 0, foreach: notifications">
                <div class="summary alert alert-success alert-dismissable">
                    <button type="button" class="close" data-dismiss="alert" aria-hidden="true">×</button>
                    <p data-bind="text: $data"></p>
                </div>
            </div>

            <div class="new-post pad-bottom" data-bind="visible: signedIn">
                <form data-bind="submit: writePost">
                    <div class="form-group">
                        <label for="message">Write a new post:</label>
                        <textarea class="form-control" name="message" id="message" placeholder="New post"></textarea>
                    </div>
                    <button type="submit" class="btn btn-default">Submit</button>
                </form>
            </div>

            <ul class="posts list-unstyled" data-bind="foreach: posts">
                <li>
                    <p>
                        <span data-bind="text: username" class="username"></span><br />
                    </p>
                    <p>
                        <span data-bind="text: message"></span>
                    </p>

                    <p class="no-pad-bottom date-posted">Posted <span data-bind="text: moment(date).calendar()" /></p>

                    <div class="comments" data-bind="visible: $parent.signedIn() || comments().length > 0">
                        <ul class="list-unstyled" data-bind="foreach: comments, visible: comments().length > 0">
                            <li>

                                <p>
                                    <span class="commentor" data-bind="text: username"></span>
                                    <span data-bind="text: message"></span>
                                </p>
                                <p class=" no-pad-bottom date-posted">Posted <span data-bind="text: moment(date).calendar()" /></p>
                            </li>
                        </ul>

                        <form class="add-comment" data-bind="visible: $parent.signedIn, submit: addComment">
                            <div class="row">
                                <div class="col-md-9">
                                    <input type="text" class="form-control" name="comment" placeholder="Add a comment" />
                                </div>
                                <div class="col-md-3">
                                    <button class="btn btn-default" type="submit">Add Comment</button>
                                </div>
                            </div>
                        </form>
                    </div>
                </li>
            </ul>
        </div>
    </div>

</div>

@section scripts {
    <script src="~/Scripts/moment.js"></script>
    <script src="~/Scripts/jquery.signalR-2.0.3.min.js"></script>
    <script src="~/signalr/hubs"></script>
    <script src="~/Scripts/knockout-3.1.0.js"></script>
    <script src="~/Scripts/board.js"></script>
}

Add a bit of CSS - We have a few custom CSS classes on top of what Bootstrap provides. Currently, /Content/Site.css is in your style bundle. Open it and replace everything above the validation helper classes with this:

.pad-bottom {
    margin-bottom: 10px;
}

.no-pad-bottom {
    margin-bottom: 0;
}

.new-post {
    background-color: #c9e0fc;
    padding: 15px 10px;
}

.username {
    font-weight: bold;
    color: #ff6a00;
}

.commentor {
    font-weight: bold;
    color: #004bff;
}

.posts li .date-posted {
    font-size: 12px;
    font-style: italic;
}

.posts li {
    border-bottom: 1px solid #CCC;
    padding: 15px 0;
}

.posts li:first-child {
    border-top: 1px solid #CCC;
}

.posts .comments {
    background-color: #efefef;
    margin-top: 10px;
    padding: 10px;
    padding-left: 30px;
}

.posts .comments li {
    padding-top: 10px;
    border: 0;
}

form.add-comment  {
    margin-top: 10px;
    margin-bottom: 10px;
}

The JavaScript

Create a script - In the Scripts directory, make a new script called board.js. This script will contain the client-side logic for the application.

Edit the script - Let's begin with our script.

A message board is made of posts and comments to those posts. Let's define those objects.

var post = function (id, message, username, date) {
    this.id = id;
    this.message = message;
    this.username = username;
    this.date = date;
    this.comments = ko.observableArray([]);

    this.addComment = function (context) {
        var comment = $('input[name="comment"]', context).val();
        if (comment.length > 0) {
            $.connection.boardHub.server.addComment(this.id, comment, vm.username())
            .done(function () {
                $('input[name="comment"]', context).val('');
            });
        }
    };
}

var comment = function (id, message, username, date) {
    this.id = id;
    this.message = message;
    this.username = username;
    this.date = date;
}

A submit has an observable variety of remarks. This enables it in order that when new remarks come in, it's immediately displayed within the view.

We've outlined our submit and remark objects. Now let's define our view design that is the glue from the application.

var vm = {
    posts: ko.observableArray([]),
    notifications: ko.observableArray([]),
    username: ko.observable(),
    signedIn: ko.observable(false),
    signIn: function () {
        vm.username($('#username').val());
        vm.signedIn(true);
    },
    writePost: function () {
        $.connection.boardHub.server.writePost(vm.username(), $('#message').val()).done(function () {
            $('#message').val('');
        });
    },
}

ko.applyBindings(vm);

We have an observable array of posts (which have an observable array of remarks). We even have an observable assortment of notifications, which inform customers of latest posts or comments on their posts. Our view model tracks the username and if a user is signed in. Finally, a view design can include techniques.

Next, we've a way for loading posts, which is known as when the web page hundreds and the user connects into a SignalR hub. The posts are loaded from the Net API controller which we are going to make later. Each and every submit is additional to the observable assortment of posts. Each and every from the post's feedback are added to the comments observable variety of the submit. This really is a really verbose method of performing this, but I wanted to make it distinct what was happening right here.

function loadPosts() {
$.get('/api/posts', function (data) {
    var postsArray = [];
    $.each(data, function (i, p) {
        var newPost = new post(p.Id, p.Message, p.Username, p.DatePosted);
        $.each(p.Comments, function (j, c) {
            var newComment = new comment(c.Id, c.Message, c.Username, c.DatePosted);
            newPost.comments.push(newComment);
        });

        vm.posts.push(newPost);
        });
    });
}

The rest of the script has to do with SignalR connections and methods. We'll get back to that later. Below is the entire board.js script.

var post = function (id, message, username, date) {
    this.id = id;
    this.message = message;
    this.username = username;
    this.date = date;
    this.comments = ko.observableArray([]);

    this.addComment = function (context) {
        var comment = $('input[name="comment"]', context).val();
        if (comment.length > 0) {
            $.connection.boardHub.server.addComment(this.id, comment, vm.username())
            .done(function () {
                $('input[name="comment"]', context).val('');
            });
        }
    };
}

var comment = function (id, message, username, date) {
    this.id = id;
    this.message = message;
    this.username = username;
    this.date = date;
}

var vm = {
    posts: ko.observableArray([]),
    notifications: ko.observableArray([]),
    username: ko.observable(),
    signedIn: ko.observable(false),
    signIn: function () {
        vm.username($('#username').val());
        vm.signedIn(true);
    },
    writePost: function () {
        $.connection.boardHub.server.writePost(vm.username(), $('#message').val()).done(function () {
            $('#message').val('');
        });
    },
}

ko.applyBindings(vm);

function loadPosts() {
    $.get('/api/posts', function (data) {
        var postsArray = [];
        $.each(data, function (i, p) {
            var newPost = new post(p.Id, p.Message, p.Username, p.DatePosted);
            $.each(p.Comments, function (j, c) {
                var newComment = new comment(c.Id, c.Message, c.Username, c.DatePosted);
                newPost.comments.push(newComment);
            });

            vm.posts.push(newPost);
        });
    });
}

$(function () {
    var hub = $.connection.boardHub;
    $.connection.hub.start().done(function () {
        loadPosts(); // Load posts when connected to hub
    });

    // Hub calls this after a new post has been added
    hub.client.receivedNewPost = function (id, username, message, date) {
        var newPost = new post(id, message, username, date);
        vm.posts.unshift(newPost);

        // If another user added a new post, add it to the activity summary
        if (username !== vm.username()) {
            vm.notifications.unshift(username + ' has added a new post.');
        }
    };

    // Hub calls this after a new comment has been added
    hub.client.receivedNewComment = function (parentPostId, commentId, message, username, date) {
        // Find the post object in the observable array of posts
        var postFilter = $.grep(vm.posts(), function (p) {
            return p.id === parentPostId;
        });
        var thisPost = postFilter[0]; //$.grep returns an array, we just want the first object

        var thisComment = new comment(commentId, message, username, date);
        thisPost.comments.push(thisComment);

        if (thisPost.username === vm.username() && thisComment.username !== vm.username()) {
            vm.notifications.unshift(username + ' has commented on your post.');
        }
    };
});

The Data Layer - We will be making use of Entity Framework as well as the Code First sample for our straightforward info layer.

Inside the Models directory, develop a brand new C# class referred to as MessageBoard.cs. Our data designs are little, and in our scenario we'll just place them in a single file alongside with all the data context.

using System;
using System.Collections.Generic;
using System.ComponentModel.DataAnnotations;
using System.Data.Entity;
using System.Linq;
using System.Web;

namespace MessageBoardTutorial.Models
{
    public class MessageBoardContext : DbContext
    {
        public DbSet<Post> Posts { get; set; }
        public DbSet<Comment> Comments { get; set; }
    }

    public class Post
    {
        [Key]
        public int Id { get; set; }
        public string Message { get; set; }
        public string Username { get; set; }
        public DateTime DatePosted { get; set; }
        public virtual ICollection<Comment> Comments { get; set; }
    }

    public class Comment
    {
        [Key]
        public int Id { get; set; }
        public string Message { get; set; }
        public string Username { get; set; }
        public DateTime DatePosted { get; set; }
        public virtual Post ParentPost { get; set; }
    }
}

Although the actual database doesn't yet exist, it will likely be produced if the application deems it essential. Should you maintain your internet.config unchanged, it's going to develop it within your LocalDB instance of SQL Server Specific.

The API

The script requirements a technique to get in touch with to get the posts to the concept board. Whilst we could just tack a technique on to our HomeController that would try this, we can equally as effortlessly create an ASP.Web Internet API controller which will fetch and immediately convert the posts into a JSON format.

Create the API Controller - In the Solution Explorer, right click on the Controllers directory and click on Add > Web API Controller Class (v2) in the context menu. Add a new Web API controller and call it PostsController.cs

Write the API
- Replace the code with the below. Our API will simply return a JSON or XML-serialized array of all of the posts and comments on the message board when a client calls http://[yoursite]/api/posts.

using System;
    using System.Collections.Generic;
    using System.Linq;
    using System.Net;
    using System.Net.Http;
    using System.Web.Http;
    using MessageBoardTutorial.Models;

    namespace MessageBoardTutorial.Controllers
    {
        public class PostsController : ApiController
        {
            private MessageBoardContext _ctx;
            public PostsController()
            {
                this._ctx = new MessageBoardContext();
            }

            // GET api/<controller>
            public IEnumerable<post> Get()
            {
                return this._ctx.Posts.OrderByDescending(x => x.DatePosted).ToList();
            }
        }
    }
</post></controller>

Handle circular references - If you look at our data models, a Post contains a virtual collection of comments, and a Comment contains a virtual Post that refers to the comment's parent. This circular reference will freak out Web API's serialization method. To solve this, just add the following line of code to the Register method in the WebApiConfig class located at App_Start/WeApiConfig.cs

config.Formatters.JsonFormatter.SerializerSettings.ReferenceLoopHandling =
    Newtonsoft.Json.ReferenceLoopHandling.Ignore;

Circular references will now be ignored.

Implementing the SignalR Hub

SignalR provides a relationship between clientele and also the server. Clients connect to a SignalR Hub. The Hub can then contact client-side occasions on a single, some, or all related clients. The Hub tracks which consumers are linked to it. This can be the center of real-time net programs. Within our case, a client generates a fresh submit or comment, which phone calls a method around the Hub. The Hub then calls a method on all of the message board's connected users that inserts the brand new submit or remark.

In a nutshell, the awesomeness of SignalR is that it may call JavaScript capabilities on any browser linked to it. The outdated assemble is clientele could only get in touch with server-side features. This type of functionality could only be achieved via long-polling (a customer working an infinite loop that calls a server method).


Newer browsers connect to hubs via HTML 5 web sockets. For older browsers, there are long-polling and "forever frame" fallbacks.

Map the hubs - In order for SignalR to begin and for the web application to map the connection hubs, we must create an OWIN startup class. Lucky for us, this just involves a couple of clicks and a line of code. Right-click on the solution and add a new item. Find the OWIN Startup Class template. Name this file "Startup.cs". Now, you just have to add one line of code in the Configuration method to map the hubs.

using System;
using System.Threading.Tasks;
using Microsoft.Owin;
using Owin;

[assembly: OwinStartup(typeof(MessageBoardTutorial.Startup))]

namespace MessageBoardTutorial
{
    public class Startup
    {
        public void Configuration(IAppBuilder app)
        {
            app.MapSignalR();
        }
    }
}

Create the Hub - Make a new directory in the root of your project called Hubs. Now, right-click on this new directory and click on Add > New Item... in the context menu. Create a new SignalR Hub Class called BoardHub.cs.


Replace the code in the file with the below:

using System;
using System.Collections.Generic;
using System.Linq;
using System.Web;
using Microsoft.AspNet.SignalR;
using MessageBoardTutorial.Models;

namespace MessageBoardTutorial.Hubs
{
    public class BoardHub : Hub
    {
        public void WritePost(string username, string message)
        {
            var ctx = new MessageBoardContext();
            var post = new Post { Message = message, Username = username, DatePosted = DateTime.Now };
            ctx.Posts.Add(post);
            ctx.SaveChanges();

            Clients.All.receivedNewPost(post.Id, post.Username, post.Message, post.DatePosted);
        }

        public void AddComment(int postId, string comment, string username)
        {
            var ctx = new MessageBoardContext();
            var post = ctx.Posts.FirstOrDefault(p => p.Id == postId);

            if (post != null)
            {
                var newComment = new Comment { ParentPost = post, Message = comment, Username = username, DatePosted = DateTime.Now };
                ctx.Comments.Add(newComment);
                ctx.SaveChanges();

                Clients.All.receivedNewComment(newComment.ParentPost.Id, newComment.Id, newComment.Message, newComment.Username, newComment.DatePosted);
            }
        }
    }

}

The Hub contains a method for writing a new post and a method for writing a new comment. Both methods are called from the client and ultimately call client-side methods for connected users.

For example, the writePost client-side method is called when a user writes a new post:

writePost: function () {
    $.connection.boardHub.server.writePost(vm.username(), $('#message').val()).done(function () {
        $('#message').val('');
    });
},

This method calls the WritePost method on the Hub. After the new post is added to the database, the Hub then calls the receivedNewPost method on all connected clients.

Clients.All.receivedNewPost(post.Id, post.Username, post.Message, post.DatePosted);

From BoardHub.cs

hub.client.receivedNewPost = function (id, username, message, date) {
    var newPost = new post(id, message, username, date);
    vm.posts.unshift(newPost);

    // If another user added a new post, add it to the activity summary
    if (username !== vm.username()) {
        vm.notifications.unshift(username + ' has added a new post.');
    }
};

From board.js

The Hub sends info about the new submit to this client method, which then helps make a brand new Publish JavaScript object and adds it to the starting from the view model's posts observable array. This new post is instantaneously displayed for all related customers since Knockout is observing this array. A brand new notification can also be produced for all customers other than the creator of the new publish.

Adding a remark follows the same pattern, although the client callback method differs marginally:

hub.client.receivedNewComment = function (parentPostId, commentId, message, username, date) {
    // Find the post object in the observable array of posts
    var postFilter = $.grep(vm.posts(), function (p) {
        return p.id === parentPostId;
    });
    var thisPost = postFilter[0]; //$.grep returns an array, we just want the first object

    var thisComment = new comment(commentId, message, username, date);
    thisPost.comments.push(thisComment);

    if (thisPost.username === vm.username() && thisComment.username !== vm.username()) {
        vm.notifications.unshift(username + ' has commented on your post.');
    }
};

The ID of the parent post of the comment is sent to the client, which then adds the new comment to the comments observable array of the post

Finally, let us run this point

Now you can construct and operate the project! Ooo is in dire need of a social community.

Go on and open up two browser windows and "log in" as a various person on every. Recognize how once you include a submit in a single window, it instantaneously is additional towards the other window in addition to a notification. Now, the Ice King can annoy princesses on-line too! Effectively, possibly that is not all that good.




Cheap ASP.NET 4.5 Hosting

We’re a company that works differently to most. Value is what we output and help our customers achieve, not how much money we put in the bank. It’s not because we are altruistic. It’s based on an even simpler principle. "Do good things, and good things will come to you".

Success for us is something that is continually experienced, not something that is reached. For us it is all about the experience – more than the journey. Life is a continual experience. We see the Internet as being an incredible amplifier to the experience of life for all of us. It can help humanity come together to explode in knowledge exploration and discussion. It is continual enlightenment of new ideas, experiences, and passions


Author Link

 photo ahp banner aspnet-01_zps87l92lcl.png



Corporate Address (Location)

ASPHostPortal
170 W 56th Street, Suite 121
New York, NY 10019
United States

Tag cloud

Sign in
